Docs / design system v0.1
Uranium, refined just enough to be dangerous. This is the kit Fradiation Games is built from: earthling-ui primitives, a reactor's worth of tokens and effects, and components that treat every click like a game mechanic. Everything on this page is live.
00yellowcake
Yellowcake is the Fradiation Games design system: earthling-ui primitives, dressed for a reactor. Five rules decide the close calls.
01
Every interaction is a mechanic.
Clicks have weight, holds charge up, hovers answer back. But the fun version is never slower than the boring one. If it adds a step, it has to replace a worse one (see HoldButton vs. confirm dialogs).
02
Loud chrome, quiet content.
Glow, glitch and scanlines frame things. They never sit on top of text you need to read, and a game's own screen is never overlaid.
03
Deadpan.
The voice is an Adult Swim bumper: short, dry, a little ominous. Jokes can be lowercase. Anything about money, safety, or data is plain and clear.
04
Honest labels.
Engine, AI involvement and content warnings are always visible on the card, never buried on the detail page.
05
The viewer controls the dose.
Sound is off until they turn it on. CRT scanlines have a switch. prefers-reduced-motion kills all spatial motion. Hotkeys stay out of text fields and running games.
01yellowcake
A redraw of the original: the glossy trefoil is now geometric (ISO 361 proportions), the green glow ring became a containment ring that opens where the blades point, and the stacked-outline italic wordmark is now outlined Anybody with a rad-green extrusion. Masters live in Figma: ☢ Yellowcake — Brand & Tokens.
use hero moments, the HUD, anything that needs to say the name. avoid below 120px wide (use the mono variant or the mark).
<Wordmark /> // color: gradient + rad extrusion
<Wordmark variant="mono" games={false} className="text-bone-100" />use favicon, avatars, loading, and anywhere the name won't fit.
<Trefoil glow />
<Trefoil spin />
<Trefoil variant="mono" ring={false} />use headers, email, social cards.
<Lockup className="text-5xl" />use one per page, as the hero. It's interactive: tap it. avoid as decoration in lists; it's a full WebGL context.
// client only — loads three.js lazily
import { ReactorCore } from "@/yellowcake/brand/reactor-core-lazy";
<ReactorCore field className="h-96" />02yellowcake
Primitives are 'isotopes'. Components use the semantic tokens (earthling-ui's names), so a theme swap is one class. Pairs are checked: bone on lead-950 is 15.9:1, ash-400 on lead-900 is 5.6:1, void on rad-400 is 15.7:1.
lead — neutrals, green-tinted. Backgrounds, surfaces, borders.
void
lead-950
lead-900
lead-800
lead-700
lead-600
lead-500
ash-400
ash-300
bone-100
bone-50
rad — primary. Actions, focus, glow, 'good'.
rad-300
rad-400
rad-500
rad-600
rad-700
rad-900
hazard — secondary. Warnings, loud bands, the wordmark. 500 is the 2019 site's yellow.
hazard-300
hazard-400
hazard-500
hazard-600
core — heat. Gradient base, gamma tier. 600 is the 2019 site's orange.
core-400
core-500
core-600
melt — danger, destructive, meltdown.
melt-400
melt-500
melt-700
cher — Cherenkov blue. Legendary tier, info, AI-assisted.
cher-300
cher-400
cher-600
mutant — glitch splits and AI-generated only.
mutant-400
use in components. Never hard-code a primitive where a role exists.
bg-surface text-foreground border-border
bg-primary text-primary-foregrounduse one loud band per page: tickers, callouts, the odd principle.
Theme swap
Everything inverts.
Semantic tokens flip; components come along for free.
<section className="theme-hazard">…</section>03yellowcake
Anybody for display (variable width, run it wide), Archivo for reading, Martian Mono for the HUD, Silkscreen for the loud little pixel bits. All self-hosted through next/font.
use expanded for shouting, condensed for dense labels. Drag it.
Fradiation
className="font-display [font-stretch:140%]"04yellowcake
Durations: blip 90 · quick 160 · base 260 · slow 480 · epic 900ms (--dur-*). Everything spatial turns off under prefers-reduced-motion. Sounds are synthesized with WebAudio at runtime, so there are no files to download, and they're silent until the viewer turns them on.
use duration-(--dur-base) ease-(--ease-snap)
use sfx.clunk() on commit, sfx.blip() on hover, sfx.tick() for counters.
import { sfx } from "@/yellowcake/sfx/sfx";
sfx.confirm();05yellowcake
Industrial containers, and the effects that make the place glow. Effects are CSS utilities first; WebGL only where nothing else will do.
use the default container for grouped content.
Chamfered equipment panel with a stencil label strip and rivets. The chamfer is drawn by clipped layers, so focus rings inside stay visible.
For anything with consequences.
<Panel label="Specimen data" meta="0x2f" hazard>…</Panel>use headlines only; one effect per line.
EXTRUDED
Core gradient
phosphor glow
<GlitchText text="…" trigger="hover" />
className="text-extrude" // hard extrusion
className="text-core-gradient"
className="text-glow".hazard-stripes
Hazard tape. Add animate-hazard-march for a belt.
.scanlines
CRT lines as a background layer.
.bg-blueprint
Lab graph paper; the default stage.
.grain
Film grain. Static, cheap.
.chamfer
Cut corners. Clips outlines too, so focus rings go on a parent.
.chamfer-top
Top corners only, for trays that rise from the bottom edge.
.shadow-glow-*
rad · hazard · melt · cher. Light, not shadow.
use a ticker per page, max. Pauses on hover; static with reduced motion.
<Marquee label="Bulletins" className="theme-hazard py-2">…</Marquee>use section backgrounds. It's the 2019 site's ripple shader, ported: brand colors, pointer-reactive, renders at low resolution and pauses offscreen.
Move your mouse.
<section className="relative isolate">
<ReactorField intensity={0.6} />
<div className="relative">…</div> // content above; avoid negative z-index
</section>06yellowcake
Controls are physical: they sit on a slab, sink when pressed, and click. All of them are real buttons and switches underneath (earthling-ui / ARIA), so keyboards and screen readers get the plain version of the joke.
use actions. One rad or hazard button per view; ghost for the rest.
<RadButton tone="hazard" size="lg" icon="icon-[lucide--play]">Play</RadButton>
<RadButton asChild tone="ghost"><Link href="/vault">Vault</Link></RadButton>use destructive actions, instead of an 'Are you sure?' dialog. avoid anything that happens often.
Hold with pointer, Space or Enter. Deleted 0×.
<HoldButton action="delete" onConfirm={remove} />use settings with consequences: mature content, public visibility, wiping saves.
Show games flagged for gore, language, or themes.
○ Safe
<SafetySwitch label="Mature content" checked={on} onCheckedChange={setOn} />use every form. Field wires the label, hint and error to whatever control its render prop returns.
Shown on every card.
That slug is taken.
<Field label="Title" error={err} hint="Shown on the card.">
{({ id, describedBy, invalid }) => <TextInput id={id} aria-describedby={describedBy} aria-invalid={invalid} />}
</Field>use one (or several) of a short list: engine, origin, AI flags, report reasons. Arrow keys move between chips. avoid lists longer than about eight; use a select.
<ChoiceChips choices={ENGINES} value={engine} onValueChange={setEngine} />
<ChoiceChips multiple choices={FLAGS} value={flags} onValueChange={setFlags} />use file intake: builds, covers. Goes hazard-yellow while something hovers over it. Folders get their own button.
Drop a zipped build here, or or .
<Dropzone label="a zipped build" accept=".zip" onFile={read} onFolder={readFolder} />use progress with a known end: uploads, charge. Lit segments, like the cabinet loader.
<SegmentMeter value={sent / total} label="Upload progress" tone="rad" />use a value people share: playtest links, codes. Focus selects it; the button copies and says so.
<CopyField value={url} label="Playtest link" />07yellowcake
0 to 5 in half steps, like Newgrounds. Every band has a word, so a score reads at a glance: Inert, Trace, Warm, Hot, Critical, Meltdown.
use the rating input. Sweep to hear it tick faster; click to lock it in.
<GeigerRating value={v} onChange={setV} />use read-only scores on cards, lists and reviews.
<RatingMeter value={4.5} />08yellowcake
A game is a collectible: tilt, foil, scanlines, a PLAY reticle. Engine and AI origin are always on the card. (Ratings and play counts here are demo values.)
Vaultby fradiation
by demo
by demo
by demo
use EngineTag + OriginTag on every card and game page. Pixel tags for loud flags only.
<EngineTag engine="godot" /> <OriginTag origin="ai-assisted" />
<Tag pixel tone="hazard">New!</Tag>use where a game is in draft → containment → released / buried, and how long judgment has left. GameCard takes flag="contained" and a footer for the countdown.
<StatusTag status="containment" />
<Countdown to={game.judgmentEndsAt} done="Closing" />09yellowcake
XP is 'rads'. Rads set your exposure level (0 Clean → 9 Meltdown). Mutations are achievements; rarity is named for radiation: alpha, beta, gamma, and cherenkov for the legendary ones. Games declare their own in fradiation.json and unlock them through the SDK. Signed in, the server keeps score; anonymous progress stays in the browser and its easter eggs transfer when you get a badge.
use (demo meter — the buttons don't touch your real dose)
Exposure level
Exposed
165rads absorbed
135 rads to Irradiated
<DoseMeter rads={rads} />
<DoseMeter rads={rads} variant="compact" /> // HUDuse profiles, game pages, unlock toasts.
Row two is your real progress. One of them is a secret.
<MutationBadge mutation={m} unlocked={has(m.id)} size="md" />10yellowcake
The public profile (/u/handle) is facility ID: clearance (level), status, dose, mutations, and a barcode that's unique to the handle. Badges come from Discord or GitHub sign-in plus a handle claimed on /welcome.
Name
@fradiation
Issued Flash era
<IdCard name="…" handle="…" rads={…} joined="…" mutations={…} />use sign-in prompts. These are live: they really sign you in.
<ProviderButton provider="discord" />
useSite.getState().setSignInOpen(true) // the full dialoguse anywhere a person appears in a list. Level pip optional.
<Avatar image={u.image} name={u.name} level={3} />11yellowcake
Comments and reviews (Transmission in code). The like button is 'Irradiate' and it doses the reader a couple of rads. Devs are marked. (Demo thread.)
played this in 2008 on a library computer and got kicked off for laughing. still holds up. the second level is a war crime.
the second level is a war crime. that part was intentional.
controls feel like steering a shopping cart through soup. 2/5 would get irradiated again.
<Transmission author={u} time="3h ago" rating={4.5}>…</Transmission>use posting and replying. The counter goes hot near the limit; ⌘/Ctrl+Enter sends.
<TransmissionComposer onSubmit={async (body) => (await postTransmission({ slug, body })).ok} />12yellowcake
System messages come over the facility PA: hazard-edged toasts in a polite live region. Hover pauses them. Doses float up from where they happened. Anything that needs an answer opens a dialog.
useSite.getState().announce({ tone: "good", title: "Upload complete", icon: "icon-[lucide--circle-check]" })use after any server action that returns a dose; the rads rise from the pointer and unlocks get announced.
const r = await rateGame({ slug, value });
if (r.ok) useSite.getState().applyDose(r.dose, { x: e.clientX, y: e.clientY });use every popup: forms, setup steps, sign-in, reports. A hatch on desktop, a tray from the bottom edge on a phone. Tone colors the tape: hazard by default, melt for reports and anything destructive, rad for good news. avoid confirming a delete; that's a HoldButton. Status after the fact; that's a toast.
<RadDialog open={open} onOpenChange={setOpen}>
<RadDialogContent tone="hazard" size="md">
<RadDialogHeader eyebrow="Label" meta="0x2F">
<RadDialogTitle>…</RadDialogTitle>
<RadDialogDescription>…</RadDialogDescription>
</RadDialogHeader>
<RadDialogBody>…</RadDialogBody> // scrolls
<RadDialogFooter>…</RadDialogFooter> // stays put; primary last
</RadDialogContent>
</RadDialog>13yellowcake
The cabinet every game runs in, whatever the engine: title bar, click-to-start, restart, fullscreen, letterboxing. The game only mounts after start. Hosted builds run inside it as a <GameFrame>: a sandboxed iframe on the separate play origin, talking to the site only through @fradiation/sdk.
Bouncerflash · as2 · ruffle
Insert coin
use hosted builds (Three.js, Unity, Godot, HTML5), inside a GameStage. Live example: /games.
Sandbox: allow-scripts allow-same-origin allow-pointer-lock allow-popups allow-modals. No top navigation, ever.
Handshake: the game says hello → the site checks it came from this iframe and the play origin → hands over a private MessageChannel port.
<GameStage title={t} width={w} height={h}>
{() => <GameFrame src={buildUrl(slug, hash)} playOrigin={PLAY_ORIGIN}
player={viewer} onUnlockMutation={…} onSubmitScore={…} />}
</GameStage>use per-game boards declared in fradiation.json. Top three lit; the viewer's row marked.
<Scoreboard name="High score" format="number" order="desc" top={rows} viewerHandle={me} />14yellowcake
Long-form pages are Markdown (content/docs), rendered into Yellowcake: GitHub alerts become callouts, fenced code becomes a code block with a copy button. The raw Markdown stays readable for agents at /docs/<slug>.md.
use a note, tip, warning or caution inside running text. avoid page-level status; that's a toast.
<Callout tone="warning">Paths must be relative.</Callout>
> [!WARNING] (the same, in Markdown)
> Paths must be relative.use commands, configs and snippets people copy; wrap for prose, like a prompt. avoid inline code; use <code>.
node check-build.mjs pack Builds/FradiationUse the fradiation MCP server to put this game on Fradiation: wire in the SDK with a few mutations and a high-score board, then deploy it to a draft.{
"viewport": { "width": 1280, "height": 720 },
"mutations": []
}<CodeBlock lang="bash" code={cmd} />15yellowcake
Adult Swim bumper, not a children's cereal box. Short and dry. The theme lives in the mechanics (rads, mutations, containment) and in the odd line of flavor; navigation, labels, forms and errors just say what they are. If a word needs explaining, it's the wrong word.
Panel label
Specimen data
Details
Empty state
No games yet. Be the first to upload!
No games yet. Check back soon.
Flavor (one per page, at most)
Welcome to the reactor. Please enjoy your stay!
Everything, contaminated.
Destructive
Are you sure you want to delete?
Hold to delete.
Error (keep plain)
Something went wrong :(
Upload failed: index.html must be at the top of the zip.
